Filter Prima Klima Industry line K1609 - 810-1090 m3/h, 200mm

Code: 1694
Stock in Europe

K1609 - professional carbon filter Prima Klima Industry line K1609 - 810 / 1090m3 / h for pipes with a diameter of 200mm. Odor resistance up to 2 years, possibility of refurbishment.

Detailed information

Product detailed description

The Prima Klima Industry Line premium carbon filters are characterised by a remarkably high durability and an incomparable odour adsorption. The filters are refillable and have a 4cm deep bed of first quality, highly activated CTC75-3mm carbon with a active surface area of >1200m2/g. This ensures an exceptionally long contact time between air and carbon, which is highly effective for removing odours. High-quality metal press parts provide maximum stability and durability. The extra-long flange provides a secure connection.

The Prima Klima Industry line K1609 - 810 / 1090m3 / h is an ideal component of medium and large ventilation systems with a pipeline of 200mm diameter. Industry Line is a professional line of filters long-term favorite thanks to its high performance and reliability. The advantage is also higher charcoal density and up to 2 years resistance to odor without the need to replace the carbon charge. The First Climate odor end filters can be used vertically or horizontally and can be rebuilt after the service life has elapsed


  High durability
  Effective particle adsorption and odour removal
  4cm deep bed of highly activated carbon
  Optimal contact time
  High quality metal parts
  With pre-filter against dust


Recommended ventilators: PK200-A, PK200-L, PK200-2


Additional parameters

Category: Prima Klima Industry Filters
Warranty: 2 years
Activated carbon: CTC80-3mm 5.3Kg
Diameter: 280mm
Filter flow: up to 1000m3
Flange: 200mm
Incl. pre-filter: K1709
Length: 500mm w/o flange
Max Airflow: 1090m³/h
Optimal Airflow: 810m³/h
Weight: 8.3Kg
