XL4 COB Array 400w - 520w (UV/IR) 3500k COBs

Code: 8445/4 P
from €929 from €767,77 excl. VAT

Choose variant

XL4 COB ARRAY is a fully customizable COB Array that allows you to adjust each COB independently to give you the light distribution and intensity you desire.

Detailed information

XL4 COB Array 400w - 520w (UV/IR) 3500k COBs: 4 pcs Optic 1XL+120w Bloom Enchancer
Stock in Europe | 8445/4 P
€929
€767,77 excl. VAT
XL4 COB Array 400w - 520w (UV/IR) 3500k COBs: 4 pcs Optic 1XL+120w Bloom Enchancer + Hang Frame
Stock in Europe | 8445/4 P2
€939
€776,03 excl. VAT

Product detailed description

 XL4 COB ARRAY is a fully customizable COB Array that allows you to adjust each COB independently to give you the light distribution and intensity you desire. Plug and play ready high yielding setup gives you an easy to use system that utilizes the best of modern LED technology making it easier for you to get the amazing results your looking for. CREE's XLAMP CXB3590 has now been unleashed with the amazingly powerful Optic







Options for Your COB Array:

  1. FOUR Optic 1 XL 100 watt COBs (120 degree Lenses included);
  2. ONE Far Red Bloom Enhancer;
  3. Optional 4x4 (1.2m) Aluminum Hanging Frame (42" x 32" (540mm x 810mm). (Frame is not included.)

XL4 COB Array Specifications:

  • COBs: CREE XLAMP CXB-3590 (3500k Daylight White)
  • Bloom Enhancers: OSRAM 3W LEDs



  • Lens120 degree Crystal Clear Wide Beam Lenses
  • Bloom Enhancer Driver:  Meanwell 120 Watt Dimmable Driver
  • Optic 1XL Drivers: Meanwell 100 Watt Driver
  • Dimmer: 10% - 100% Dimmability (Bloom Enhancer Only)



  • Thermal management: Passive Cooling from Overbuilt heatsinks
  • PPF/Watt:  2.45 umol/J (Bloom Enhancer) / 2.1 umol/J (COBs)
  • Actual Power Draw: 520 watt max draw
  • LEDs Max Power: 744 Watts
  • Grams Per Watt: Up to 2.25
  • Yield: Up to 1170 grams / 41.78 ounces (2.61lbs)

(Optic 1 and Optic 1XL yields increased to 2.25 Grams Per Watt )



Coverage Footprint:

  • Flower:
  • 4' x 4' area (.1.2m x .1.2m)
  • Max 5' x 5' (1.5m x 1.5m)

Hanging Height:

  • Flower: 12"- 24" (.3m - .6m)
  • Veg: 24"-36" (.6m - .9m)
  • Seedling: 36"+ (.9m+)



PPFD FAR RED BLOOM ENHANCER ARRAY (Average PAR):

2' x 2' Area @12" (.3m) Hanging Height PPFD: 810

 (Tested with Apogee MQ-500 PAR Meter)

PAR Meter Reading @12" (center of footprint)

PPFD for XL4 COB ARRAY @520 watts: 15" Hanging Height

PPFD: 732



18" Hanging Height

PPFD: 687

(Tested Using Apogee MQ-500 PAR Meter)



Spectrum of Bloom Enhancer: Full Spectrum + FAR RED + UV & IR



Spectrum of Bloom Enhancer & COBs Combined:

(Full Spectrum + FAR RED + Ultra Violet & Infrared)



Description:

  • Lifetime: 100,000 Hours
  • Warranty: Lifetime Warranty (10 Years)
  • Shipping: Free Shipping to over 100 countries
  • Light Fixture: Four Optic 1XL + Far Red Bloom Enhancer
  • Cables: 6 Foot attached power cord with On/Off Switch
  • Plug: USA, UK, EURO, Canada, Africa, Australia & many more
  • Dimming: On/Off Switch & 10% - 100% Dimmability
  • Hanger: Rope Ratchets included for all fixtures
  • Recommended for: Grow Tents, Grow Rooms, All Grow Spaces



Note: All products are shipped from the European Union. All lights have an EU plug, we only ship UK plugs to England and Malta.
